    Stainless Steel 304 2 inch Normally Closed Solenoid Valve for Water AC 24V

    Ask Lasest Price
    Brand Name : AFK
    Model Number : 2W-500-50B
    Supply Ability : 30000 Set/Sets per Week
    Price : Negotiable
    Certification : CE
    • Product Details
    • Company Profile

    Stainless Steel 304 2 inch Normally Closed Solenoid Valve for Water AC 24V

    Stainless Steel 304 2 inch Normally Closed Solenoid Valve for Water AC 24V
    1) Model: 2W-500-50B
    2) Pipe size: 2 inch
    3) Orifice size : 50 mm
    4) Connection: G , NPT
    5) Medium: Air, water, oil
    6.Working Pressure:
    (water, air )0~10kgf/cm²
    (Oil) : 0~7 kgf/cm²
    7.Body Material : Stainless steel
    8.Seal:Below 80℃ use NBR,
    Below 120℃use EPDM,
    Below 150℃ use VITON
    Characteristic
    1. The direct-acting type diaphragm structure without pressure to open to extend the using field.
    2. Using the plate diaphragm structure opening and closing with reliable. Then extent the product life.
    3.Can choose plastic type, explosion-proof energy-saving.
    4. Switching element of modern industrial pipeline.
    5. Start and stop with eletromagnetic force.
    6. Dust elimination and filter should go ahead of use of medium.
    DESIGN FEATURES
    1. Direct acting
    2. Fit for air, water, oil , the neutral gas liquid.
    3. Type: normally closed.
    4.Pipe size from 1/8' to 2' .
    5. Service voltage : AC380V, 220V,110V,24V DC24,12V
    6.Thread connnector : G, NPT
    7. Material: Stainless steel
    8.Large flow.
    Structure Parameters

    Model NO.
    2W-200-20B
    2W-250-25B
    2W-320-32B
    2W-400-40B
    2W-500-50B
    Pipe size
    3/4'
    1'
    1 1/4‘’
    1 1/2‘’
    2‘’
    Orifice size
    20mm
    25mm
    32mm
    40mm
    50mm
    CV value
    7.6
    12
    24
    29
    48
    Fluid
    Air water oil, the neutral gasliquid
    Servise voltage
    AC380V AC220V AC110V AC24V DC24V DV12V ( allow ± 10%)
    Operating
    Type
    Normally Closed
    Body Material
    viscosity
    ( Below )20CST
    Working pressure
    ( water, air ) :0~10 kgf/cm² ( oil ) : 0~7 kgf/m²
    Material of seal
    Standard : below 80℃ fluid temperature use NBR, below 120℃ use EPDM, below 150℃ use VITON
    Packing & Delivery
    Stainless Steel 304 2 inch Normally Closed Solenoid Valve for Water AC 24V
    Packaging
    Size
    17cm*17cm*17cm
    Weight
    Different size has different weight
    Packaging Details
    The normal package is wooden box(Size: L*W*H). Or according to customers special request.
